DATABOOK RESISTOR

Riconosciuta in tutto il mondo, la certificazione UL è sinonimo di garanzia di sicurezza e qualità del prodotto, testimonia le numerose prove svolte in laboratorio con precisione e attenzione.

Per questo Fairfild sceglie di offrire al cliente un prodotto sicuro ed affidabile, che abbia superato tutti i controlli qualità necessari a garantire efficienza durante il suo utilizzo.

Affidarsi a resistenze con marchio UL vuol dire utilizzare un prodotto costruito secondo gli standard previsti dalle normative, dove la sicurezza elettrica è valutata sotto ogni aspetto.

Clicca a questo link per scaricare il file .PDF delle nostre Resistenze UL.

Le nostre resistenze certificate:

The RFK is a wire resistance wound on a mica cement coated plate, immersed in quartzite sand and placed in an anodized aluminium casing. Sealing is carried out using silicone elastomer and aluminium cap.

Scarica il Data Sheet delle RFK

MODEL RATED POWER OPERATING VOLTAGE IP RESISTANCE VALUE (MIN – MAX) POWER TERMINALS I mm [inch] L mm [inch] WEIGHT kg [lb]
RFK 250 75 600 IP65 1.5 : 3600 Flexible Wiring Leads AWG14 98 [3.86] 113 [4.45] 0.32 [0.70]
RFK 350 100 600 IP65 4 : 2400 Flexible Wiring Leads AWG14 148 [5.83] 163 [6.42] 0.5 [1.1]
RFK 500 150 600 IP65 3 : 1800 Flexible Wiring Leads AWG14 204 [8.03] 219 [8.62] 0.63 [1.39]

The RFD is a wire resistance wound on a mica cement coated plate, immersed in quartzite sand and placed in an anodized aluminium casing. The sealing is done by silicone elastomer. Version with thermal pad called the RFDT can be purchased also.

Thermal switch upon request – Scarica il Data Sheet delle RFD

MODEL RATED POWER OPERATING VOLTAGE IP RESISTANCE VALUE
(MIN – MAX)		 POWER TERMINALS L mm [inch] L1 mm [inch] I mm [inch] I1 mm [inch] H mm [inch] d mm [inch] WEIGHT kg [lb]
RFD 50 25 600 IP55 2 : 6000 Flexible Wiring Leads AWG14 100[3.94] 40[1.57] No holes No holes 15[0.59] No holes 0.16[0.35]
RFD 100 45 600 IP55 2 : 4500 Flexible Wiring Leads AWG14 100[3.94] 60[2.36] 88[3.46] 40[1.57] 15[0.59] 5[0.2] 0.22[0.48
RFD 150 75 600 IP55 1.5 : 3600 Flexible Wiring Leads AWG14 110[4.33] 80[3.15] 98[3.86] 60[2.36] 15[0.59] 5[0.2] 0.32[0.7]
RFD 200 100 600 IP55 4 : 2400 Flexible Wiring Leads AWG14 160[6.3] 80[3.15] 148[5.83] 60[2.36] 15[0.59] 5[0.2] 0.5[1.1]
RFD 300 150 600 IP55 3 : 1800 Flexible Wiring Leads AWG14 216[8.5] 80[3.15] 204[8.03] 60[2.36] 15[0.59] 5[0.2] 0.63[1.39]
RFD 550 200 600 IP55 2.5 : 1500 Flexible Wiring Leads AWG14 220[8.66] 100[3.94] 180[7.09] 83.5[3.29] 20[0.79] 6.3[0.25] 0.98[2.16]

The RFX is a wire resistance wound on a mica coated cement plate enclosed in a galvanised sheet case that is not sealed. Versions are available with built-in winding. Version with clixon called the RFXT is also available.

Scarica il Data Sheet delle RFX

MODEL RATED POWER OPERATING VOLTAGE IP RESISTANCE VALUE (MIN – MAX) POWER TERMINALS L mm [inch] I mm [inch] WEIGHT kg [lb]
RFX 600 75 600 IP20 1.5 : 3600 Flexible Wiring Leads AWG14 105[4.13] 81[3.19] 0.26[0.57]
RFX 1300 150 600 IP20 3 : 1800 Flexible Wiring Leads AWG14 198[7.79] 174[6.85] 0.46[1.01]

The RFZ/C is a resistance made of an aluminium heat-sink with coiled wire inserted in perforated ceramic and filled with quartzite sand.

The metal case is sealed with silicone elastomer.

Model RFZT/C is identical to model RFZ/C with the addition of the clixon.

With Thermal Switch

MODEL RATED POWER OPERATING VOLTAGE IP RESISTANCE VALUE (MIN – MAX) POWER TERMINALS L mm [inch] I mm [inch] WEIGHT kg [lb]
RFZ/C 100 70 600 IP55 1.1 : 39 Flexible Wiring Leads AWG14 100[3.94] 85[3.35] 0.18[0.4]
RFZ/C 160 100 600 IP55 3.0 : 100 Flexible Wiring Leads AWG14 160[6.3] 145[5.71] 0.3[0.66]
RFZ/C 200 125 600 IP55 3.9 : 120 Flexible Wiring Leads AWG14 200[7.87] 185[7.28] 0.38[0.84]
RFZ/C 260 160 600 IP55 5.6 : 150 Flexible Wiring Leads AWG14 260[10.24] 245[9.64] 0.5[1.1]
RFZ/C 300 185 600 IP55 6.2 : 200 Flexible Wiring Leads AWG14 300[11.81] 285[11.22] 0.57[1.26]
RFZ/C 320 140 600 IP55 6.8 : 220 Flexible Wiring Leads AWG14 320[12.6] 305[12.01] 0.6[1.32]
RFZT/C 100 50 600 IP55 1.1 : 39 Flexible Wiring Leads AWG14 100[3.94] 85[3.35] 0.18[0.4]
RFZT/C 160 70 600 IP55 3.0 : 100 Flexible Wiring Leads AWG14 160[6.3] 145[5.71] 0.3[0.66]
RFZT/C 200 90 600 IP55 3.9 : 120 Flexible Wiring Leads AWG14 200[7.87] 185[7.28] 0.38[0.84]
RFZT/C 260 115 600 IP55 5.6 : 150 Flexible Wiring Leads AWG14 260[10.24] 245[9.64] 0.5[1.1]
RFZT/C 300 130 600 IP55 6.2 : 200 Flexible Wiring Leads AWG14 300[11.81] 285[11.22] 0.57[1.26]
RFZT/C 320 140 600 IP55 6.8 : 200 Flexible Wiring Leads AWG14 320[12.6] 305[12.01] 0.6[1.32]

The RFP is a wire resistance wound on a mica plate, immersed in quartzite sand and placed in an anodized aluminium casing. Sealing is done through dielectric cement. The cables are made of PTFE. The RFP resistance exists in the Vertical version (RFP/V) and the horizontal version (RFP/H). Only the version marked UL can be purchased. Other versions available are those with thermal switch, (RFP T) those with built-in fuse (RFP F) and the version with thermostat and fuse (RFP FT).

Thermal switch upon request – Scarica il Data Sheet delle RFP

MODEL RATED POWER OPERATING VOLTAGE IP RESISTANCE VALUE (MIN – MAX) POWER TERMINALS L mm [inch] I mm [inch] WEIGHT kg [lb]
RFP 200-V 200 1000 IP64 1 : 220 Flexible Wiring Leads AWG14 167[6.57] 147[5.79] 0.52[1.15]
RFP 200-H 200 1000 IP64 1 : 220 Flexible Wiring Leads AWG14 167[6.57] 147[5.79] 0.52[1.15]
RFP 300-V 300 1000 IP64 1.8 : 390 Flexible Wiring Leads AWG14 217[8.54] 197[7.75] 0.7[1.54]
RFP 300-H 250 1000 IP64 1.8 : 390 Flexible Wiring Leads AWG14 217[8.54] 197[7.75] 0.7[1.54]
RFP 400-V 370 1000 IP64 2.7 : 560 Flexible Wiring Leads AWG14 267[10.51] 247[9.72] 0.9[1.98]
RFP 400-H 300 1000 IP64 2.7 : 560 Flexible Wiring Leads AWG14 267[10.51] 247[9.72] 0.9[1.98]
RFP 500-V 500 1000 IP64 3.3 : 820 Flexible Wiring Leads AWG14 337[13.27] 317[12.48] 1.15[2.53]
RFP 500-H 400 1000 IP64 3.3 : 820 Flexible Wiring Leads AWG14 337[13.27] 317[12.48] 1.15[2.53]

VERTICAL  VERSION (V)

HORIZONTAL VERSION (H)

Thanks to this construction the thermal resistance is very low: the wire is free to exchange heat with the surrounding air very efficiently.

Even in terms of the heat capacity the RMS ensures very high performances. Stainless steel terminals for screws M6, very robust design for high energy pulses and heavy overload.

Scarica il Data Sheet delle RMS

MODEL RATED POWER OPERATING VOLTAGE IP RESISTANCE VALUE (MIN – MAX) POWER TERMINALS L mm [inch] I mm [inch] ⌀ A mm [inch] WEIGHT kg [lb]
RMS 5 500 : 700 1000 IP00 1.0 : 51 Connection bar screw Metric M6 380[14.96] 340[13.38] 20[0.79] 1.05[2.31]
RMS 6 840 : 1200 1000 IP00 1.2 : 63 Connection bar screw Metric M6 440[17.32] 400[15.75] 20[0.79] 1.2[2.64]
RMS 7 945 : 1350 1000 IP00 1.5 : 74 Connection bar screw Metric M6 500[19.68] 460[18.11] 20[0.79] 1.35[2.98]
RMS 8 1050 : 1400 1000 IP00 1.8 : 86 Connection bar screw Metric M6 560[22.05] 520[20.47] 20[0.79] 1.5[3.31]
RMS 9 1225 : 1600 1000 IP00 2.0 : 100 Connection bar screw Metric M6 620[24.41] 580[22.83] 20[0.79] 1.6[3.53]
RMS 10 1400 : 1800 1000 IP00 2.3 : 110 Connection bar screw Metric M6 700[27.56] 650[25.59] 27[1.06] 1.7[3.75]

RME series contains coiled coil resistors. The frame of the enclosure is made of galvanized steel and has an IP20 degree of protection. The power terminals are available on a clamp and are located within the terminal box, which can be opened. The box is equipped with thermal switch with proper terminal in the terminal box.

Thermal switch upon request – Scarica il Data Sheet delle RME 01S

MODEL RATED POWER OPERATING VOLTAGE IP RESISTANCE VALUE (MIN – MAX) POWER TERMINALS
RME 01S 600 800 IP20 2.2 : 100 Clamp max cable section 6 mm^2

RME series contains coiled coil resistors. The frame of the enclosure is made of galvanized steel and has an IP20 degree of protection. The power terminals are available on a clamp and are located within the terminal box, which can be opened. The box is equipped with thermal switch with proper terminal in the terminal box.

Thermal switch upon request – Scarica il Data Sheet delle RME 01M

MODEL RATED POWER OPERATING VOLTAGE IP RESISTANCE VALUE (MIN – MAX) POWER TERMINALS
RME 01M 900 800 IP20 4.7 : 180 Clamp max cable section 6 mm^2

RME series contains coiled coil resistors. The frame of the enclosure is made of galvanized steel and has an IP20 degree of protection. The power terminals are available on a clamp and are located within the terminal box, which can be opened. The box is equipped with thermal switch with proper terminal in the terminal box.

Thermal switch upon request – Scarica il Data Sheet delle RME 02M

MODEL RATED POWER OPERATING VOLTAGE IP RESISTANCE VALUE (MIN – MAX) POWER TERMINALS
RME 02M 1700 800 IP20 2.2 : 220 Clamp max cable section 6 mm^2

RME series contains coiled coil resistors. The frame of the enclosure is made of galvanized steel and has an IP20 degree of protection. The power terminals are available on a clamp and are located within the terminal box, which can be opened. The box is equipped with thermal switch with proper terminal in the terminal box.

Thermal switch upon request – Scarica il Data Sheet delle RME 01L

MODEL RATED POWER OPERATING VOLTAGE IP RESISTANCE VALUE (MIN – MAX) POWER TERMINALS
RME 01L 1275 800 IP20 6.3 : 270 Clamp max cable section 6 mm^2

RME series contains coiled coil resistors. The frame of the enclosure is made of galvanized steel and has an IP20 degree of protection. The power terminals are available on a clamp and are located within the terminal box, which can be opened. The box is equipped with thermal switch with proper terminal in the terminal box.

Thermal switch upon request – Scarica il Data Sheet delle RME 02L

MODEL RATED POWER OPERATING VOLTAGE IP RESISTANCE VALUE (MIN – MAX) POWER TERMINALS
RME 02L 1900 800 IP20 3.3 : 220 Clamp max cable section 6 mm^2

RME series contains coiled coil resistors. The frame of the enclosure is made of galvanized steel and has an IP20 degree of protection. The power terminals are available on a clamp and are located within the terminal box, which can be opened. The box is equipped with thermal switch with proper terminal in the terminal box.

Thermal switch upon request – Scarica il Data Sheet delle RME 03L

MODEL RATED POWER OPERATING VOLTAGE IP RESISTANCE VALUE (MIN – MAX) POWER TERMINALS
RME 03L 3300 800 IP20 2.2 : 180 Clamp max cable section 6 mm^2

RME series contains coiled coil resistors. The frame of the enclosure is made of galvanized steel and has an IP20 degree of protection. The power terminals are available on a clamp and are located within the terminal box, which can be opened. The box is equipped with thermal switch with proper terminal in the terminal box.

Thermal switch upon request – Scarica il Data Sheet delle RME 04L

MODEL RATED POWER OPERATING VOLTAGE IP RESISTANCE VALUE (MIN – MAX) POWER TERMINALS
RME 04L 4500 800 IP20 1.5 : 180 Clamp max cable section 6 mm^2

RX series uses RMS nude wire-wound elements. The frame of the enclosure is made of galvanized steel and has an IP23 degree of protection. The power terminals are nickel plated brass screw terminals and are found inside a terminal box. The box is equipped with thermal switch with proper terminal on the external side of the framework.

Thermal switch upon request – Scarica il Data Sheet delle RX 21S

MODEL RATED POWER OPERATING VOLTAGE IP RESISTANCE VALUE (MIN – MAX) POWER TERMINALS
RX 21S 4500 1000 IP23 0.33 : 220 Bolt metric M10

RX series uses RMS nude wire-wound elements. The frame of the enclosure is made of galvanized steel and has an IP23 degree of protection. The power terminals are nickel plated brass screw terminals and are found inside a terminal box. The box is equipped with thermal switch with proper terminal on the external side of the framework.

Thermal switch upon request – Scarica il Data Sheet delle RX 35S

MODEL RATED POWER OPERATING VOLTAGE IP RESISTANCE VALUE (MIN – MAX) POWER TERMINALS
RX 35S 8500 1000 IP23 0.27 : 110 Bolt metric M10

RX series uses RMS nude wire-wound elements. The frame of the enclosure is made of galvanized steel and has an IP23 degree of protection. The power terminals are nickel plated brass screw terminals and are found inside a terminal box. The box is equipped with thermal switch with proper terminal on the external side of the framework.

Thermal switch upon request – Scarica il Data Sheet delle RX 50S

MODEL RATED POWER OPERATING VOLTAGE IP RESISTANCE VALUE (MIN – MAX) POWER TERMINALS DRAWING Nr.
RX 50S 15000 1000 IP23 0.39 : 62 Bolt metric M10 16

RX series uses RMS nude wire-wound elements. The frame of the enclosure is made of galvanized steel and has an IP23 degree of protection. The power terminals are nickel plated brass screw terminals and are found inside a terminal box. The box is equipped with thermal switch with proper terminal on the external side of the framework.

Thermal switch upon request – Scarica il Data Sheet delle RX 65S

MODEL RATED POWER OPERATING VOLTAGE IP RESISTANCE VALUE (MIN – MAX) POWER TERMINALS
RX 65S 20000 1000 IP23 0.51 : 47 Bolt metric M10

The RNP is a resistance with strip wrapped edgeways on ceramic U-bolts mounted on a metal rod. Thanks to this construction the thermal resistance is very low: the strip is in fact free to exchange heat with the surrounding air very effectively. Even in terms of the heat capacity the RNP ensures very high performances. The RNP series does not provide default ohmic values or predetermined resistive alloys. Only the length of the bar is fixed.

Scarica il Data Sheet delle RNP

MODEL RATED POWER OPERATING VOLTAGE IP RESISTANCE VALUE (MIN – MAX) POWER TERMINALS
RNP 800 495 ÷ 890 600 IP00 0.1 ÷ 2.7 Connection bar screw Metric
RNP 1000 619 ÷ 1105 600 IP00 0.12 ÷ 3.6 Connection bar screw Metric
RNP 1200 742 ÷ 1350 600 IP00 0.15 ÷ 4.3 Connection bar screw Metric

The RNT is a resistance with strip wrapped edgeways on ceramic brackets mounted on a metal tie rod or threated ceramic tube. Thanks to this construction the thermal resistance is very low: the strip is in fact free to exchange heat with the surrounding air very effectively. Even in terms of the heat capacity the RNT ensures very high performances. The RNT series does not provide default ohmic values or predetermined resistive alloys.

Scarica il Data Sheet delle RNT

MODEL RATED POWER OPERATING VOLTAGE IP RESISTANCE VALUE (MIN – MAX) POWER TERMINALS
RNT 2 275 ÷ 477 600 IP00 0.051 ÷ 1.21 Connection bar screw Metric
RNT 3 447 ÷ 778 600 IP00 0.083 ÷ 1.97 Connection bar screw Metric
RNT 4 621 ÷ 1080 600 IP00 0.115 ÷ 2.74 Connection bar screw Metric
RNT 5 795 ÷ 1381 600 IP00 0.147 ÷ 3.5 Connection bar screw Metric
RNT 6 966 ÷ 1550 600 IP00 0.18 ÷ 4.27 Connection bar screw Metric

MODEL RATED POWER OPERATING VOLTAGE IP RESISTANCE VALUE (MIN – MAX) POWER TERMINALS
RNT 700 487 ÷ 794 600 IP00 0.11 ÷ 0.81 Connection bar screw Metric
RNT 900 581 ÷ 922 600 IP00 0.14 ÷ 0.75 Connection bar screw Metric
RNT 1000 797 ÷ 1000 600 IP00 0.12 ÷ 0.71 Connection bar screw Metric
RNT 1100 766 ÷ 1250 600 IP00 0.08 ÷ 0.44 Connection bar screw Metric
